Durable Natural Rubber Ship Launching Heavy Lifting Airbags

Brand Name : Jerryborg

Model Number : 1.2m*15m

Certification : ISO17357 CCS BV

Place of Origin : Shandong, China

MOQ : negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 5000 pieces per year

Delivery Time : 10-20 work days

Packaging Details : nude packing

material : natural rubber

color : black

size : 0.8×12.0m

part : inflatable tool,pull ring, pressure guage

certificate : CCS,BV,ABS

shape : cylindrical body

warranty : 24 months

thickness : 4-10 layers

place of origin : Qingdao,China

Price : negotiable

Contact Now

1.2m*15m Marine Inflatable Roller Bag Natural Rubber Heavy Duty Lifting Airbag

Marine Inflatable Roller Bag Description

Marine inflatable roller bag used for ship launching is a cylindrical airbag body with two conical heads and end openings. The end openings are equipped with airtight rotary joints and air intake devices. Marine inflatable roller bags are accepted by more and more shipyards worldwide due to its’ advantage of saving labor cost and time, besides it’s easy to install and replace. Marine inflatable roller bags are widely used in ship launching, ship salvage, and other heavy weights lifting and moving.

Marine inflatable roller bags are composed of inner reinforced synthetic-tire-cord layers and outer rubber layers in the shape of cylindrical. Marine inflatable roller bags are not limited to space and heavy machinery, they can effectively shorten the construction period and save a lot of money.

Marine Inflatable Roller Bag Advantages

  • Saving labor cost and time
  • Lightweight and easy to deploy
  • Durable aging resistance and anti-wear characteristic
  • New design of anti-bursting construction at the end
  • Beyond space limitation

Marine Inflatable Roller Bag Application

  • Weight moving & lifting
  • Caissons lifting and floating
  • Ship launching and upgrading
  • Ship salvage
  • Pipeline blocking

Durable Natural Rubber Ship Launching Heavy Lifting Airbags

Constructions Of Marine Inflatable Roller Bag

  • Structure: outer rubber layer, inner rubber layer, synthetic tire cord layer
  • Cord layers: 4-10 layers
  • Shape: a cylindrical body, two heads
  • Accessories: pressure gauge, pull ring, three-way piece, ball valve, connecting pipe

Durable Natural Rubber Ship Launching Heavy Lifting Airbags

Marine Inflatable Roller Bag Specification

Series Model Diameter(m) Working Pressure(Mpa) Working Height(m) Beating Capacity(Ton/m)
0.4D 0.5D 0.6D 0.4D 0.5D 0.6D
S1

S10

 0.8 0.20 0.32 0.40 0.48 15.1 12.6 10.0
1 0.16 0.40 0.50 0.60 15.1 12.6 10.0
1.2 0.14 0.48 0.60 0.72 15.8 13.2 10.6
1.5 0.11 0.60 0.75 0.90 15.5 13.0 10.4
S11 0.8 0.19 0.32 0.40 0.48 14.3 11.9 9.5
1 0.15 0.40 0.50 0.60 14.1 11.8 9.4
1.2 0.13 0.48 0.60 0.72 14.7 12.2 9.8
1.5 0.10 0.60 0.75 0.90 14.1 11.8 9.4
S12 0.8 0.24 0.32 0.40 0.48 18.1 15.1 12.1
1 0.19 0.40 0.50 0.60 17.9 14.9 11.9
1.2 0.16 0.48 0.60 0.72 18.1 15.1 12.1
1.5 0.13 0.60 0.75 0.90 18.4 15.3 12.2
1.8 0.10 0.72 0.90 1.08 17.0 14.1 11.3
S2 S20 1 0.24 0.40 0.50 0.60 22.6 18.8 15.1
1.2 0.20 0.48 0.60 0.72 22.6 18.8 15.1
1.5 0.16 0.60 0.75 0.90 22.6 18.8 15.1
1.8 0.13 0.72 0.90 1.08 22.0 18.4 14.7
2 0.12 0.80 1.00 1.20 22.6 18.8 15.1
S21 1 0.27 0.40 0.50 0.60 25.4 21.2 17.0
1.2 0.23 0.48 0.60 0.72 26.0 21.7 17.3
1.5 0.18 0.60 0.75 0.90 25.4 21.2 17.0
1.8 0.15 0.72 0.90 1.08 25.4 21.2 17.0
2 0.14 0.80 1.00 1.20 26.4 22.0 17.6
S22 1 0.31 0.40 0.50 0.60 29.2 24.3 19.5
1.2 0.26 0.48 0.60 0.72 29.4 24..5 19.6
1.5 0.20 0.60 0.75 0.90 28.3 23.6 18.8
1.8 0.17 0.72 0.90 1.08 28.8 24.0 19.2
2 0.15 0.80 1.00 1.20 28.3 23.6 18.8
2.5 0.12 1.00 1.25 1.50 28.3 23.6 18.8
S3 S30 1 0.35 0.40 0.50 0.60 33.0 27.5 22.0
1.2 0.29 0.48 0.60 0.72 32.8 27.3 21.9
1.5 0.23 0.60 0.75 0.90 32.5 27.1 21.7
1.8 0.19 0.72 0.90 1.08 32.2 26.8 21.5
2 0.17 0.80 1.00 1.20 32.0 26.7 21.4
2.5 0.14 1.00 1.25 1.50 33.0 27.5 22.0
For further information free to contact us.
